VIOLI KOREA

WEIGHT

10.9kg

(Carrier block and pedals excluded)

MAX. LOAD

Recommended height: 145–185cm

Maximum load: 95kg

FRAME

Material: 4130 Chromoly

Folding system: Half-folding

Wheel size: 20" (451mm)

Hub width: Front 100mm, Rear 135mm

Carrier block mount: 3 holes

WHEELSET

Rim: Carbon material (Height: 30mm, Internal width: 18.4mm, External width: 25mm)
Spokes: Stainless steel (28 pieces)
Wheelset specification: 20" (ETRTO: 451mm)
Wheelset bearings: 2 in the front, 4 in the rear high-speed shield bearings
Tires: Schwalbe® ONE 20x1-1/8 85-115psi Black Skin
Tubes: 20x1-1/8 Presta type valve

SPEED

Front Derailleur: Microshift® CENTOS FD-R58F-BK 2-speed
Rear Derailleur: Microshift® CENTOS R58S-BK 11-speed
Shift Shifter: Microshift® CENTOS SL-R761
Shift Cable: JAGWIRE® FLEX-SL
Chainring: 46-30T
Crankset: 170mm GXP type Hollowtech Crankset
Cassette: Shimano® CS-R7000 11-28T 11-speed
Bottom Bracket: 68mm Hollowtech type
Chain: Shimano® CN-HG601 11-speed Silver

BRAKE

Brake Type: Hydraulic Disc Brake
Brake Caliper: Shimano® Altus BR-MT200
Brake Lever: Shimano® Altus BL-MT200
Brake Hose: Shimano® SM-BH59-JK
Rotor: Φ160mm 6-hole

HANDLE

Handlebar: 25.4x580mm Lightweight Alloy Black Anodized Flatbar
Grip: Flat Type Lock Grip
Handle Post: Aluminum 3D Forged Integrated One-Touch Folding Lever Type
(Handlebar Angle and Height Adjustment, Right-side Folding)
Handlebar QR Lever: Trigo® TRP2398 Speedometer Mount Integrated

SEAT

Seat: Violi® Prostate Type

Black Leather Seat
Seatpost: 31.8x580mm Lightweight Alloy Black 2-Bolt Type

· There may be slight deviations in length, weight, and other specifications.
· Specifications are subject to change due to year model updates and product/process improvements.
