WEIGHT

11.05kg (Carrier block and pedals excluded)

MAX.LOAD

H. 145~185cm
W.95kg

FRAME

· Frame material: 4130 Chromoly
· Fork material: 4130 Chromoly
· Folding type: Half-fold
· Wheel size compatibility: 20" 406mm ~ 20" 451mm
· Hub spacing: Front 100mm, Rear 135mm
· Carrier block holes: 3 holes

WHEELSET

· Rim: Aluminum
· Spokes: Stainless steel
· Size: 20" (ETRTO: 406mm)
· Bearings: High-speed sealed bearings, Front 2, Rear 4
· Tires: Schwalbe® KOJAK 20x1.35 (34-406)
· Tubes: 20x1.35 Presta valve type

SPEED

· Derailleur: L-TWOO® T9 RD-T1110 11-speed
· Shifter: L-TWOO® T9 SL-T1110 11-speed
· Chainring: 47T (with integrated chainring guard)
· Crank: Violi® 170mm BCD130 lightweight aluminum hollow tech
· Cassette sprocket: Sunshine® 11-42T (11-13-15-17-19-21-24-28-32-36-42)
· Bottom bracket: 68mm hollow tech type
· Chain: SUMC® 11-speed silver

BRAKE

· Brake type: Hydraulic disc brake
· Brake caliper: SHIMANO® Altus BR-MT200
· Brake pad: SHIMANO® B01S resin type
· Brake lever: SHIMANO® Altus BL-MT200

HANDLE

· Handlebar: Φ25.4x580mm lightweight aluminum flat bar
· Grip: Classic synthetic leather-wrapped 130mm lock grip
· Handlepost: 2-bolt fixed lightweight aluminum 3D forged integrated type
(Handlebar angle adjustment, Handlebar height adjustment,
Dual safety one-touch folding lever, Right side folding)

SEAT

· Violi® prostate-type black leather saddle
· Seatpost: Φ31.8x580mm lightweight aluminum 2-bolt type
